    4-Way 100 kHz – 250 MHz Power Combiner – 1200 W

    CO-4-0.1-250-1200-NF-NF
    Part number: 001488

    This Toroidal Magnetic Core Power Combiner covers the 100 kHz-250 MHz frequency range, and can output up to 1200 W of continuous power. This device shows a great VSWR <1.2:1 and a high isolation of 15 dB. As all our products it is made in-house and comes a 3 years warranty.

    Stock: 0
    Add to compareRequest quotation

    Additional Information

    Ways

    4

    Fmin (MHz)

    0.1

    Fmax (MHz)

    250

    Insertion losses (dB)

    0.4

    Input VSWR

    1.2:1

    Output VSWR

    1.2:1

    Isolation (dB)

    15

    Amplitude Balance (dB)

    -/+ 0.1

    Phase Balance (°)

    5

    Power Handling (W)

    1200

    Input Connectors

    N

    Output Connector

    N

    Warranty

    3 years

    Product Description

    This power combiner (PN 001488) allows you to merge 4 in-phase signals into 1 on the 100 kHz – 250 MHz frequency range. It can output up to 1200 W CW on a large operating temperature range of 0°C to +40°C. Furthermore it allows you to get the best out of your sources by having a low VSWR(<1.2:1), and low insertion losses(<0.4dB) and low phase/amplitude balance. This rugged piece of equipment shows and high isolation (15 dB min) in order to prevent your sources from damaging one another. Moreover as a Magnetic Core Power Combiner it can also be used as a power splitter with the same specifications.
